Piston ring set STD Standard – RE530613, RE507852 & RE66820

Description

Piston ring set STD Standard – RE530613, RE507852 & RE66820

Tractor Range:

Agricultural tractor: 1040, 1140, 1350, 1630, 1640, 1654, 1750, 1840, 1850, 1850N, 1854, 1950, 1950N, 2040, 2040s, 2054, 2104, 2130, 2140, 2150, 2155, 2250, 2350, 2355, 2450, 2550, 2650, 2650N, 2750, 2755, 2850, 2855N, 2750, 2755, 2850, 2855N, 2950, 2955, 3040, 3050, 3055, 3100, 3100, 3140, 3150, 3155, 3200, 3200X, 3210, 3210X, 3255, 3300, 3300X, 3350, 3400, 3400X, 3410, 3410X, 3640, 4040, 4040S, 4050, 5080R, 5080RN, 5090, 5090RN, 5100R, 5100RN, 5105M, 5105ML, 6100, 6100SE, 6110, 6110SE, 6130, 6200, 6200SE, 6210, 6210SE, 6230, 6230 Premium, 6300, 6300SE, 6310, 6310S, 6310SE, 6330, 6330 Premium, 6400, 6400SE, 6410, 6410S, 6410SE, 6430, 6430 Premium, 6500, 6510S, 6530, 6530 Premium, 6530, 6530 Premium, 6534, 6600, 6610, 6610SE, 6630, 3360 Premium, 6800, 6810, 6830, 6830 Premium, 6900, 6910, 6930, 6930 Premium, 7130, 7130 Premium, 7230, 7230 Premium, 7230 Premium, 7330 Premium, 7430 Premium, 7530 Premium, 8320, 840, 940
Combine harvester: 1157, 1170, 1175, 1470, 2054, 2254
Cotton picker: 9910, 9920
Power unit: 3029D, 3029T, 3179D, 3179T, 4039D, 4039T, 4045D, 4045T, 4239D, 4239T, 6059T, 6068D, 6068T, 6359D, 6359T
Self-propelled sprayer: 4630
Telescopic/Materials handlers: 3800, 4400, 4500

Dimensions
Top ring width: 3.16mm
Top ring type: Key stone wedge with internal chamfer
Second ring width: 2.39mm
Second ring type: Taper face with reverse internal chamfer
Third ring width: 3.46mm
Third ring type: Oil control ring with coil spring

Original equipment manufacturer’s names and part numbers are quoted for reference purposes only, and are not intended to suggest our replacement parts are made by the original equipment manufacturer.
